Optical Filters for Telecom

Build high-performance coarse wavelength division multiplexing (CWDM) and dense wavelength division multiplexing (DWDM) modules with these state-of-the-art filters.

Coherent leverages proprietary thin-film deposition process, including state-of-the-art layer thickness control, to produce the industry’s best telecom filter solutions for 200 GHz/100 GHz/50 GHz WDM components.

옵트인 네! Coherent 프로모션 Coherent 이메일로 받아보고 싶습니다.

필수 입력란

개인정보 처리방침

CWDM/DWDM Filters Specifications

Select from these CWDM/DWDM filters, or contact us about custom products including high-performance skip filters, gain-flattening filters, and dual-band filters.

데이터시트

Optical Filters for Telecom

Parameters	CWDM Filter	DWDM Filter
Operating Wavelength Range	1250 nm to 1620 nm	1250 to 1620 nm
Typical Bandwidth	13 nm to 15 nm	< 0.5 nm
Channel Spacing	20 nm	50/100/200 GHz
Central Wavelength	1271/1291/1311 nm... to 1611 nm	1520.25/1521.02/1521.79 nm… to 1577.03 nm
Transmission / Reflection Insertion Loss	< 0.35 dB
Transmission / Reflection Ripple	< 0.25 dB
Transmission Isolation for Adjacent Channel	> 30 dB
Transmission Isolation for Non-adjacent Channel	> 45 dB
Reflection Isolation	> 13 dB
Temperature Shift	< 2 pm/°C
Incidence Medium	Air
AOI	1.8 degree for 3-port coupler 13.5 degree for CCWDM	1.8 degree for 3-port coupler
Wedge	0.25 degree
Typical Size	1.2 x 1.2 x 1.0 mm, 1.4 x 1.4 x 1.0 mm	1.4 x 1.4 x 1.0 mm
